Home > products > Holographic Projection System > Musion Eyeliner 3D Holographic Laser Projection System Display , HD Video Based

Musion Eyeliner 3D Holographic Laser Projection System Display , HD Video Based

Product Details

Place of Origin: Europe

Brand Name: SMX

Certification: ROHS

Model Number: SM-HT

Payment & Shipping Terms

Minimum Order Quantity: 3x5 meter

Price: negotiation

Packaging Details: Roll Package

Delivery Time: 5 working days after received your payment

Payment Terms: T/T or western Union

Supply Ability: 1,000 sqm per month

Get Best Price
Highlight:

live hologram projection

,

holographic stage

Technology:
Pepper's Ghost
System:
Holographic Projection System
Foil Transmittance:
Up To 95%
Stage Degree:
45 Degree
Max Size Foil:
5x30 Meter
Thickness:
65um,95um
Application:
3D Hologram, Live Stage,
Delivery Time:
3-5 Days
Technology:
Pepper's Ghost
System:
Holographic Projection System
Foil Transmittance:
Up To 95%
Stage Degree:
45 Degree
Max Size Foil:
5x30 Meter
Thickness:
65um,95um
Application:
3D Hologram, Live Stage,
Delivery Time:
3-5 Days
Musion Eyeliner 3D Holographic Laser Projection System Display , HD Video Based

Musion Eyeliner 3D Holographic Laser Projection System Display , HD Video BasedLaser





Musion Eyeliner Hologram System:



HD video based 3D-projection system.

Allows holographic-type animated images to be displayed.

Large scale system allows for life-like, life-size images to be displayed.

Custom systems can be constructed for specific projects.

Systems available for rental, ideal for exhibitions and PR events.





Holographic Projection System Elements including:



Musion Eyeliner 3D Holographic Laser Projection System Display , HD Video Based 0

  • HD projector and lens - number of lumens depending on size of required projection, stage and audience.

  • Reflective surface/The bounce screen

  • HD media player - to run the HD content.

  • Our 3D-holofilm - the key ingredient to creating our 3D holographic displays

  • Our unique tension system to secure the 3D-holofilm in place.

  • Steel pipe frame to attach 3D-holofilm to the truss.

  • Stage set-up essentially a “black box" constructed using aluminum truss, black drapes, staging, lights, and a audio system.

  • 3D holographic Content Creation of a 3D-video produced HD film, animation and special effects.

  • Lighting and audio systems to add to the dramatic 3D hologram effect

Musion Eyeliner 3D Holographic Laser Projection System Display , HD Video Based 1



3D Musion Eyeliner Foil Specifications:



The image is projected full size onto a transparent screen giving the illusion that the dancers are live on stage.The transprent holographic foil is used for displaying 3D holographic images onto the stages, the foil is placed across the front of the stage at an angle of 45 degrees towards the audience; recessed below the screen is a bright image supplied by an LED screen or powerful projector. When viewed from the audience's perspective, the reflected images appear to be on the stage.



Item

Width

Length

Thickness

Transmittance

Holographic Foil

10 Meter

30 Meter

65-95um

97%

Reflectance

View Angle

Gain

Stretching Resistance

Hardness

19.70%

160 degree

2

880.LBS%

3H





Mounting Tension System Specification



--Used to fix the Holo Foil in Place

--Adjust the Foil Surface to be Flat and Tight

--Different according to Foil Size



   Musion Eyeliner 3D Holographic Laser Projection System Display , HD Video Based 2



Applications:



Live Events

Product Launches

Music Concerts

Fashion Shows

Advertising

Conference

Trade Show

Stage Hologram

     Musion Eyeliner 3D Holographic Laser Projection System Display , HD Video Based 3
