Product Details
Place of Origin: China
Brand Name: SMX
Certification: ROHS,CE
Model Number: STS100
Payment & Shipping Terms
Minimum Order Quantity: 1 Pc
Price: negotiation
Packaging Details: Professional Carton Package
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Supply Ability: 100Pcs Per Month
Custom Size: |
100 Inch |
Frame Size: |
1cm |
Gain: |
0.8 |
Keyword: |
Anti-light Projection Screen |
Weight: |
22kg |
Custom Size: |
100 Inch |
Frame Size: |
1cm |
Gain: |
0.8 |
Keyword: |
Anti-light Projection Screen |
Weight: |
22kg |
Black Diamond fixed frame screen is an ambient light-rejecting technology that features a micro-layered optical lens system that rejects light. This new technology mimics the look of a television when it is on and when it is off, but without the glare from windows or lighting fixtures. The lens-like micro layers block and absorb ambient light from above the screen surface, producing a glare and speckle-free surface that achieves optimal ambient light rejection.
The frame will be made of aluminum and finished with a black Pro-Trim fabric covering to enhance appearance and absorb light surrounding the viewing area. The frame will also be slip-jointed at corners and joints and come standard with wall-mounting brackets. It is ideal for applications in Pro AV as well as Home Theater.
Features:
1. Standard frame with Pro-Trim Black Fabric finish to absorb light surrounding the viewing area
2. Micro layers that block and absorb light
3. Ambient Light Rejecting
4. Aspect Ratio: HDTV 16:9 Format and 2.35:1
5. Product Type - Operation: Fixed Frame - Wall Mounted
6. Gain-0.8
7. 1cm Edge Frame
8. Works with ultra-short throw projector.
9. Ships unassembled and easy to install
10. Wide viewing angle
Application:
Home Theater
Room with windows and lights.
Pro AV
Parameter
| Model No. | Size | Format | View Area | Length | Packing Size | Weight | ||
| Unit:mm | Unit:mm | Unit:cm | ||||||
| Inch | (W) | (H) | (W) | (H) | cm | Kgs | ||
| FFV84 | 84 |
4:3
| 1710 | 1280 | 1910 | 1480 | 207X21X16 | 19.00 |
| FFV92 | 92 | 1870 | 1400 | 2070 | 1600 | 222X21X16 | 21.00 | |
| FFV100 | 100 | 2030 | 1520 | 2230 | 1720 | 239X21X16 | 22.00 | |
| FFV120 | 120 | 2440 | 1830 | 2640 | 2030 | 280X21X16 | 26.00 | |
| FFV150 | 150 | 3050 | 2290 | 3250 | 2490 | 337X21X16 | 30.00 | |
| FFV180 | 180 | 3660 | 2750 | 3860 | 2950 | 398X21X16 | 35.00 | |
| FFV200 | 200 | 4060 | 3050 | 4260 | 3250 | 438X21X16 | 42.00 | |
| FFH84 | 84 | 16:9 | 1860 | 1050 | 2060 | 1250 | 228X21X16 | 19.00 |
| FFH92 | 92 | 2040 | 1150 | 2240 | 1350 | 246X21X16 | 21.00 | |
| FFH100 | 100 | 2210 | 1240 | 2410 | 1440 | 264X21X16 | 23.00 | |
| FFH106 | 106 | 2350 | 1320 | 2550 | 1520 | 278X21X16 | 24.00 | |
| FFH120 | 120 | 2660 | 1500 | 2860 | 1700 | 308X21X16 | 27.00 | |
| FFH133 | 133 | 2950 | 1660 | 3150 | 1860 | 327X21X16 | 29.00 | |
| FFH135 | 135 | 2990 | 1680 | 3190 | 1880 | 331x21x16 | 31.00 | |
| FFH150 | 150 | 3320 | 1870 | 3520 | 2070 | 364x21x16 | 32.00 | |
| FFH180 | 180 | 3990 | 2240 | 4190 | 2440 | 431x21x16 | 37.00 | |
| FFH200 | 200 | 4430 | 2490 | 4630 | 2690 | 475x21x16 | 45.00 | |
| FFW100 | 100 | 2.35:1 | 2340 | 1000 | 2540 | 1200 | 274x21x16 | 23.00 |
| FFW106 | 106 | 2480 | 1060 | 2680 | 1260 | 291x21x16 | 26.00 | |
| FFW120 | 120 | 2810 | 1200 | 3010 | 1400 | 324x21x16 | 28.00 | |
| FFW133 | 133 | 3110 | 1320 | 3310 | 1520 | 343x21x16 | 30.00 | |
| FFW135 | 135 | 3160 | 1350 | 3360 | 1550 | 348x21x16 | 32.00 | |
| FFW150 | 150 | 3510 | 1490 | 3710 | 1690 | 383x21x16 | 35.00 | |
