Pepper Ghost Holographic Projection System / Holographic 3D Digital Projection

Basic Information
Place of Origin: Europe
Brand Name: SMX
Certification: ROHS
Model Number: SM-HT
Minimum Order Quantity: 3x5 meter
Price: negotiation
Packaging Details: Roll Package
Delivery Time: 5 working days after received your payment
Payment Terms: T/T or western Union
Supply Ability: 1,000 sqm per month
Detail Information
System Include: Hologram Film+ Projection System Foil Transmittance: Up To 95%
Stage Degree: 45 Degree Film Max Size: 5x30 Meter
Technology: Pepper's Ghost Thickness: 65um,95um
Film Color: Transparent Projector: Required 5000+ Lumens
High Light:

live hologram projection

,

3d holographic video projection


Product Description

Pepper Ghost Holographic Projection System / Holographic 3D Digital Projection





Musion Eyeliner Hologram System:



HD video based 3D-projection system.

Allows holographic-type animated images to be displayed.

Large scale system allows for life-like, life-size images to be displayed.

Custom systems can be constructed for specific projects.

Systems available for rental, ideal for exhibitions and PR events.

Pepper Ghost Holographic Projection System / Holographic 3D Digital Projection 0





Holographic Projection System Elements including:



Pepper Ghost Holographic Projection System / Holographic 3D Digital Projection 1

  • HD projector and lens - number of lumens depending on size of required projection, stage and audience.

  • Reflective surface/The bounce screen

  • HD media player - to run the HD content.

  • Our 3D-holofilm - the key ingredient to creating our 3D holographic displays

  • Our unique tension system to secure the 3D-holofilm in place.

  • Steel pipe frame to attach 3D-holofilm to the truss.

  • Stage set-up essentially a “black box" constructed using aluminum truss, black drapes, staging, lights, and a audio system.

  • 3D holographic Content Creation of a 3D-video produced HD film, animation and special effects.

  • Lighting and audio systems to add to the dramatic 3D hologram effect





3D Musion Eyeliner Foil Specifications:



The transprent holographic foil is used for displaying 3D holographic images onto the stages, the foil is placed across the front of the stage at an angle of 45 degrees towards the audience; recessed below the screen is a bright image supplied by an LED screen or powerful projector. When viewed from the audience's perspective, the reflected images appear to be on the stage.



Item

Width

Length

Thickness

Transmittance

Holographic Foil

10 Meter

30 Meter

65-95um

97%

Reflectance

View Angle

Gain

Stretching Resistance

Hardness

19.70%

160 degree

2

880.LBS%

3H





Mounting Tension System Specification



--Used to fix the Holo Foil in Place

--Adjust the Foil Surface to be Flat and Tight

--Different according to Foil Size



   Pepper Ghost Holographic Projection System / Holographic 3D Digital Projection 2



Applications:



Live Events

Product Launches

Music Concerts

Fashion Shows

Advertising

Conference

Trade Show

Stage Hologram
